3-inch bar 268*800 LCD ST7701 RGB interface IPS liquid crystal display module, high definition, long-term supply available

1. Module Name: 3.0-inch 268*800 LCD Screen ST7701 RGB Interface IPS LCD Display Module with Long-term Supply
2. Model:
3. Similar Models:
4. Compatible Models:
5. Display Mode: IPS
6. Display Colors: 16.7M
7. Resolution: 268*800
8. Pixel Pitch: 0.09(H)*0.09(V)
9. Viewing Angle: Full Viewing Angle
10. Driver IC: ST77001
11. Display Type: Transmissive, Normally Black
12. Outline Dimension: 26.96*80.08*1.66mm
13. Viewable Area:
14. Active Area: 24.12(H)*72.00(V)mm
15. Brightness: 400cd/m2
16. Contrast Ratio: 1000
17. Interface Type: 3SPI+16/18/24RGB
18. Pin Count: 45pin
19. Pin Pitch: 0.3mm
20. Connection Type: Plug-in
21. Operating Voltage: 3.3V
22. Backlight Color & Type: White LED Backlight
23. Backlight Circuit: 6 LEDs in series, If=20mA, Vf =16.2-19.8V
24. Service Life: 50000h
25. Operating Temperature: -20 ~+70℃
26. Storage Temperature: -30～+80℃
27. Quality System Certifications: ISO9001 ISO13485 TS16949 ISO14001 RoHS REACH

​
